Lithium Ion: Polymer Series

MATERIAL SAFETY DATA SHEET

GP Model	Nominal Voltage (V)	Capacity		Dimension (mm)	Wt (g)	Maximum Charging Voltage (V)	Maximum Charging Current (mA)
		Minimum (mAh)	Typical (mAh)
441230	3.7	95	100	4.4(T) x 12.0(W) x 30.0(H)	2.5	4.2	100
511230	3.7	120	125	5.1(T) x 12.0(W) x 30.0(H)	3.0	4.2	125
541230	3.7	135	140	5.4(T) x 12.0(W) x 30.0(H)	3.2	4.2	140
511235	3.7	155	165	5.1(T) x 12.0(W) x 35.0(H)	3.4	4.2	165
531235	3.7	165	170	5.3(T) x 12.0(W) x 35.0(H)	3.6	4.2	170
541235	3.7	180	185	5.4(T) x 12.0(W) x 35.0(H)	3.7	4.2	185
481422	3.7	95	105	4.8(T) x 14.0(W) x 22.0(H)	2.1	4.2	105
631422	3.7	130	135	6.3(T) x 14.0(W) x 22.0(H)	2.7	4.2	135
371429	3.7	95	105	3.7(T) x 14.0(W) x 29.0(H)	2.3	4.2	105
391429	3.7	105	110	3.9(T) x 14.0(W) x 29.0(H)	2.6	4.2	110
441429	3.7	130	140	4.4(T) x 14.0(W) x 29.0(H)	2.9	4.2	140
601429	3.7	165	170	6.0(T) x 14.0(W) x 29.0(H)	3.5	4.2	170
431538	3.7	195	205	4.3(T) x 15.0(W) x 38.0(H)	4.2	4.2	205
471538	3.7	230	240	4.7(T) x 15.0(W) x 38.0(H)	4.9	4.2	240
411730	3.7	140	150	4.1(T) x 17.0(W) x 30.0(H)	3.2	4.2	150
481730	3.7	190	195	4.8(T) x 17.0(W) x 30.0(H)	3.9	4.2	195
601752	3.7	450	460	6.0(T) x 17.0(W) x 52.0(H)	9.2	4.2	460
392030	3.7	170	180	3.9(T) x 20.0(W) x 30.0(H)	3.7	4.2	180
442030	3.7	195	200	4.4(T) x 20.0(W) x 30.0(H)	4.0	4.2	200
542030	3.7	250	260	5.4(T) x 20.0(W) x 30.0(H)	5.3	4.2	260
562030	3.7	270	280	5.6(T) x 20.0(W) x 30.0(H)	5.5	4.2	280
692231	3.7	400	410	6.9(T) x 22.0(W) x 31.0(H)	7.4	4.2	410
442440	3.7	360	370	4.4(T) x 24.0(W) x 40.0(H)	6.9	4.2	370
542440	3.7	450	460	5.4(T) x 24.0(W) x 40.0(H)	9.3	4.2	460
572440	3.7	480	500	5.7(T) x 24.0(W) x 40.0(H)	9.9	4.2	500
542730	3.7	370	380	5.4(T) x 27.0(W) x 30.0(H)	7.4	4.2	380
612730	3.7	410	420	6.1(T) x 27.0(W) x 30.0(H)	8.4	4.2	420
392845	3.7	450	470	3.9(T) x 28.0(W) x 45.0(H)	8.8	4.2	470
513040	3.7	530	550	5.1(T) x 30.0(W) x 40.0(H)	11.8	4.2	550
803442	3.7	1195	1225	8.0(T) x 34.0(W) x 42.0(H)	23.0	4.2	1225
453450	3.7	710	730	4.5(T) x 34.0(W) x 50.0(H)	14.2	4.2	730
643450	3.7	1060	1090	6.4(T) x 34.0(W) x 50.0(H)	19.5	4.2	1090
983450	3.7	1810	1850	9.8(T) x 34.0(W) x 50.0(H)	28.0	4.2	1850
543759	3.7	1260	1290	5.4(T) x 37.0(W) x 59.0(H)	24.0	4.2	1290
425794	3.7	2620	2690	4.2(T) x 57.0(W) x 94.0(H)	47.0	4.2	2690

*Models with UL approval
