GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh)		 Typical
(mAh)		 Dia
(mm)		 Ht
(mm)		 Current
(mA)		 Time
(hr)
GP12F7K** 9V 7.2 120 132 17.5(T) x 26.5(W) x 48.5(H) 36 12 16 Not Appl.
GP12F8K** 9V 8.4 120 132 17.5(T) x 26.5(W) x 48.5(H) 42 12 16 Not Appl.
GP15F7K** 9V 7.2 150 165 17.5(T) x 26.5(W) x 48.5(H) 36 15 16 Not Appl.
GP15F8K** 9V 8.4 150 165 17.5(T) x 26.5(W) x 48.5(H) 42 15 16 Not Appl.
*Models with UL approval



NiCd: High Drain Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh)		 Typical
(mAh)		 Dia
(mm)		 Ht
(mm)		 Current
(mA)		 Time
(hr)
GP120SCK 4/5 Sub-C 1.2 1200 1320 23 34 42 120 16 1200
GP200SCK* Sub-C 1.2 2000 2200 23 43 53 200 16 2000
GP450DK D 1.2 4500 4950 33 60 130 450 16 4500
GP500DK D 1.2 5000 5500 33 60 140 500 16 5000
*Models with UL approval



NiCd: High Temperature Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh)		 Typical
(mAh)		 Dia
(mm)		 Ht
(mm)		 Current
(mA)		 Time
(hr)
GP70AAST AA 1.2 700 770 14.4 48.2 21 70 16 Not Appl.
GP50AFKT 2/3 AF 1.2 500 550 17 28.5 15 50 16 Not Appl.
GP160SCKT Sub-C 1.2 1600 1760 23 43 44 160 16 Not Appl.
GP180SCKT Sub-C 1.2 1800 1980 23 43 46 180 16 Not Appl.
GP250CKT C 1.2 2500 2750 25.8 50 70 250 16 Not Appl.
GP300CKT C 1.2 3000 3300 25.8 50 73 300 16 Not Appl.
GP250DKT 1/2 D 1.2 2500 2750 33 37 82 250 16 Not Appl.
GP450DKT D 1.2 4500 4950 33 60.5 120 450 16 Not Appl.
GP450DKTSH D 1.2 4500 4950 33 58 120 450 16 Not Appl.
*Models with UL approval



NiCd: Standard Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh)		 Typical
(mAh)		 Dia
(mm)		 Ht
(mm)		 Current
(mA)		 Time
(hr)
GP30AAAK AAA 1.2 300 320 10.5 43.7 10.5 30 16 300
GP35AAAK AAA 1.2 350 370 10.5 43.7 12 35 16 350
GP18AAK 1/3 AA 1.2 180 200 14.5 16.6 8 18 16 180
GP30AAK 2/3 AA 1.2 300 320 14.5 28.7 11 30 16 300
GP40AAK 2/3 AA 1.2 400 450 14.5 28.7 12 40 16 400
GP50AAK 2/3 AA 1.2 500 520 14.5 28.7 13 50 16 500
GP72AAS 4/5 AA 1.2 720 760 14.4 42.5 19 72 16 720
GP100AAS* AA 1.2 1000 1030 14.4 48.2 26.5 100 16 1000
GP60AAS* AA 1.2 600 660 14.4 48.2 19 60 16 600
GP70AAS* AA 1.2 700 770 14.4 48.2 21 70 16 700
GP80AAS* AA 1.2 800 850 14.4 48.2 21 80 16 800
GP120AAK 7/5 AA 1.2 1200 1300 14.5 65 31 120 16 1200
GP25AFK 1/3 AF 1.2 250 275 17 16.3 10 25 16 250
GP55AFK 2/3 AF 1.2 550 605 17 28.5 13.9 55 16 550
GP70AFK 2/3 AF 1.2 700 770 17 28.5 16 70 16 700
GP120AFK 4/5 AF 1.2 1200 1320 17 43 26.5 120 16 1200
GP140AFK* AF 1.2 1400 1540 17 50 32.5 140 16 1400
GP200AFK 7/5 AF 1.2 2000 2200 17.5 67.5 46.3 200 16 2000
GP23NK N 1.2 230 250 12 30 8.5 23 16 230
GP130SCK Sub-C 1.2 1300 1430 23 43 44.5 130 16 1300
GP160SCK* Sub-C 1.2 1600 1760 23 43 47 160 16 1600
GP65CK* 1/2 C 1.2 650 715 25.8 23.6 29 65 16 Not Appl.
GP250DK 1/2 D 1.2 2500 2750 33 37 82 250 16 Not Appl.
*Models with UL approval



NiCd: Consumer Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh)		 Typical
(mAh)		 Dia
(mm)		 Ht
(mm)		 Current
(mA)		 Time
(hr)
GP100AAKC AA 1.2 1000 1030 14.5 50.5 26.5 100 16 1000
GP60AAKC AA 1.2 600 660 14.5 50.5 20 60 16 600
GP70AAKC AA 1.2 700 770 14.5 50.5 22 70 16 700
GP80AAKC AA 1.2 800 850 14.5 50.5 22 80 16 800
GP30AAAKC AAA 1.2 300 320 10.5 44.5 10.5 30 16 300
GP160CK C 1.2 1600 1680 26.2 50 52 160 16 Not Appl.
GP250CKC C 1.2 2500 2750 26.2 50 72 250 16 Not Appl.
GP160DK D 1.2 1600 1680 34.2 61.5 62 160 16 Not Appl.
GP450DKC D 1.2 4500 4950 34.2 61.5 135 450 16 Not Appl.
GP500DKC D 1.2 5000 5250 34.2 61.5 140 500 16 Not Appl.
*Models with UL approval
